Electric screw press (J58K)

J58K series electric screw press / suitable for all kinds of precision forging, sizing, precision pressing, leveling and other processes.

The Electric Screw Forging Press is a kind of forging equipment with strong technological applicability, which takes into account the dual properties of forging hammer and press and has the characteristics of simple structure, small volume, and short transmission chain.
A friction Forging Press is a kind of screw press with a friction drive, also known as a double disc friction press.

Electric screw press is a kind of forging and pressing equipment used for hot forging, precision forging and finishing. Electric screw press is often used in pressure welding process of stainless steel double bottom pot, and precision forging of titanium alloy blade and other blades.

Electric screw press / suitable for all kinds of precision forging, sizing, precision pressing, leveling and other processes. The hitting energy can be precisely set, the stroke is short, and the energy is stable.

The electric screw press is only lost in the blow molding process, not consumed in feeding, picking bricks, and cleaning the mold. Anyone can do it in such a short time with one key operation. Fully automatic digital simulation of human strike process

The sliding stroke of the electric screw press adopts the positioning form of long slider and long guide rail to achieve high precision and strong anti-overload and unbalanced load capacity.

1. According to the forging method: warm forging, hot forging, cold forging of thin forgings, powder metallurgy forging, straightening processing, combined casting, and forging.
2. According to forging material: all steel including stainless steel, aluminum alloy, titanium, magnesium, brass, copper, etc.

The electric screw press has good rigidity, high sliding guide precision and strong anti-eccentric load capability. It can be used for multi-station die forging. It is a new type of energy-saving and environmentally friendly press.

Anyang Forging Press is a new generation of intelligent electric screw press with more intelligent control system, better stiffness and strength, and better forging accuracy.

The electric screw press is a new type of forging equipment evolved by optimizing the transmission system on the basis of the principle of the friction press.

Electric screw presses are widely used, and many downstream fields of the forging industry require the participation of forging screw presses.

The Scope and Characteristics of the Screw Press Forging

Electric screw presses are suitable for forging various die forgings, such as turbine blades and special bolts in the aviation industry, engine valves, differential gears, connecting rods, claw poles in the automotive industry, and surgical forceps in the medical industry. With the development of science and technology, various industries have higher and higher requirements for the precision of die forgings. Compared with traditional die forging equipment, an electric screw press is ideal equipment for producing precision die forgings.

The electric spiral pressure machine has the characteristics of simple structure, small volume, short transmission chain, convenient operation, safe operation, and small maintenance workload. It is a new type of energy -saving and environmentally friendly pressure machine.

Electric screw press is a type of press machine in which the ram is driven up and down by a screw,which have the advantages of small volume,short of transmission chain,easy operation.

The Screw Press belongs to closed die forging equipment. Die forgings are widely used in automobiles, railway vehicles, construction machinery, national defense, aviation, and other fields.
In the development stage of the screw Press, there are four main transmission forms: Friction Screw Press, Hydraulic Screw Press, Clutch Screw Press, and Electric Screw Press.

The screw press is a machine that can convert the rotational energy of the flywheel into the up and down motion of the mold to do work. The origin of its earliest structure comes from the ancient printing press. Because the rotational energy can bring great energy, but the rotational energy of the flywheel must pass the screw device (screw nut) to transmit the force to the mold, which is affected by the action force and the reaction force, making the fuselage, screw, nut, etc. Force-sensitive parts are also affected by the closing force, so screw presses are especially suitable for high-energy forming machines, but the force is limited.

Electric screw press is a kind of forging equipment with strong technological applicability, taking into account the dual properties of forging hammer and press, and has the characteristics of simple structure, small size, short transmission chain, convenient operation, safe operation and small maintenance workload. It is suitable for various processes such as precision forging, finishing, precision pressing, embossing, calibration, and leveling.

Electric screw press is not only a forging equipment with strong process applicability, but also an environmentally friendly and energy-saving precision forming equipment

Electric screw press is a kind of energy-saving precision forging machine. It has the characteristics of simple structure, long service life and high precision standard of formed products. It is suitable for near-die forging, precision pressing, adjustment, bending and imprinting of medium and small workpieces.

Anyang Forging Press Company has designed complete forging “systems” that are based on the user’s technical requirements. Our goal is to create complete forging systems that deliver reliability, protect the environment, labor and energy efficiency are reliable, and above all, produce the highest quality forgings possible.
